As a manufacturer (OEM), RIGAS DIZELIS DG offers a wide range of marine gensets for main, auxiliary, emergency, emergency- harbour and other application. Units are made on the basis of top in class diesel engines such as RDS, DEUTZ, PERKINS, SCANIA, MITSUBISHI and BAUDOUIN with rated power 8 - 1708 kW.

Lorem ipsum dolor sit amet, consectetuer adipiscing elit Lorem ipsum dolor sit amet, consectetuer adipiscing elit Lorem ipsum dolor sit amet, consectetuer adipiscing elit Lorem ipsum dolor sit amet, consectetuer adipiscing elit
RDS 8 - 50 кВт
Deutz 52 - 137 кВт
Perkins 10 - 190 кВт
Scania 136 - 595 кВт
Baudouin 64 - 877 кВт
Mitsubishi 490 - 1708 кВт

AUXILIARY GENSET RANGE

Auxiliary marine series "EM" gensets are designed to work on ships of all classes, types and purposes. Units are made on the basis of modern and original diesel engines RDS, DEUTZ, PERKINS, SCANIA, MITSUBISHI AND BAUDOUIN. Available with all cooling systems which match the requirements of the classification societies: HE-double circuit with heat exchanger and seawater pump, KC – keel cooling. Alternator - synchronous type with brushless excitation system, with AVR, anti- condensate heated. On-demand - temperature sensors in the windings. Units can be automated to any degree of automation, as well as prepared for synchronization to work in parallel. Power supply for starting and control systems is 2-pin isolated 24 V or 12 V. Starting system: electric or pneumatic. Fuel system with double-walled high-pressure pipeline with leakage monitoring or without monitoring. Operation panel - microprocessor type. Depending on the design and technical requirements - additional control panel, and (or) control for remote control. Execution and completion of units depends on the specifics of the project and strictly stipulates the technical specification. Options: double (switchable) fuel pre-filters, fuel filters, oil filters, various types of air bulbs for pneumatic starter, spark arrestors, wet exhaust, a set of motorized potentiometers for synchronization to be installed in the main switchboard of the vessel, etc. Documentation – operation manuals, spare parts catalogues. Certificates of following classification societies: RMRS, RRR, BV, LR, GL, DNV and others on request.

EMERGENCY GENSET RANGE

Emergency marine "E" series gensets are made on the basis of modern and original diesel engines RDS, DEUTZ, PERKINS, SCANIA, MITSUBISHI AND BAUDOUIN. Available with following cooling systems: RC – radiator cooling, AC – air cooling type. Alternator - synchronous type with brushless excitation system, with AVR, anti- condensate heated. On-demand - temperature sensors in the windings. Units are automated. Automation microprocessor type. Power supply for starting and control systems is 2-pin isolated 24 V or 12 V. Fuel system with double-walled high-pressure pipeline with leakage monitoring or without monitoring. The main starting system - electric starter; Reserve start could be provided by the additional switchable battery pack or by the second air, hydraulic or spring starter. Execution and completion of units depends on the specifics of the project and strictly stipulates the technical specification. Options: double (switchable) fuel pre-filters, fuel filters, oil filters, additional panels for remote control and other accessories. Documentation – operation manuals, spare parts catalogues. Certificates of following classification societies: RMRS, RRR, BV, LR, GL, DNV and others on request.
